Description
For industrial teams seeking reliable, automated flow control for alcohol, water, and corrosive media, our Electric Wafer Type Ball Valve delivers precise on-off and modulating control, with a robust design optimized for continuous industrial operation and seamless automation integration.
Product type | Electric wafer type ball valve |
|---|---|
Model | PSQ972FR-16P |
Nominal diameter | NPS 1/2”~NPS 6” (DN15~DN150) |
Operating pressure | PN16, 150Lb |
Body Material | WCB, CF8, CF8M, CF3M etc |
Trim material | 304, 316, 316L |
Seat seal material | PTFE, PPL, RTFE, PEEK or metal hard seal etc. |
Connecting end | Flanged/ Welded/ Threaded |
Design standard | GB/T 12237, ASME B16.34, JIS B2071, DIN 3357 |
Face to face | G, NPT, BSPT, BSPP, DIN2999, ISO228 GB/T 15188/ 12224, ASME B16.25/ B16.11 GB/T 12221, ASME B16.10, JIS B2002, DIN 3202 |
End Connection | GB/T 9113, ASME B16.5, JIS B2212, DIN 2542 |
Inspection and test | GB/T 26480, API 598, JIS B2003, DIN 3230 |
Operation device | electric actuator |
Design Feature | 1) ISO 5211 Direct Mounting Platform 2) Investment Casting Body 3) Blowout Proof Stem 4) Optional Anti-static Device 5) Design As Customer’s Requirement |
Our electric wafer ball valve for alcohol is a specialized quarter-turn flow control valve, engineered to cut off, distribute, or adjust the flow direction of media in industrial pipelines. The valve features an integrated ISO 5211 mounting platform, allowing direct installation of electric actuators without additional brackets, ensuring precise alignment and reliable automation performance.
Driven by an electric actuator, the valve rotates the ball core 90 degrees to fully open or close the flow path, with intelligent modulating actuators available for precise flow rate adjustment. The compact wafer-style body fits seamlessly between pipeline flanges, supporting both horizontal and vertical installation to accommodate diverse pipeline layouts. This design makes the flanged wafer electric ball valve ideal for applications requiring remote or automated flow control, with minimal maintenance and easy operation.
The standard ISO 5211 mounting pad ensures direct, hassle-free installation of electric actuators, eliminating the need for custom fabrication and reducing installation time and cost. This design also ensures perfect alignment between the actuator and valve stem, minimizing wear and extending the service life of both components.
The investment casting valve body delivers uniform wall thickness and superior structural integrity, with a blowout-proof stem design that prevents stem ejection under high pipeline pressure, enhancing operational safety. High-performance seal materials, including optional metal hard seals, provide bubble-tight shutoff even in corrosive or high-cycle applications.
Available with both on-off and intelligent modulating electric actuators, the valve supports simple remote operation or precise continuous flow regulation to match your process requirements. The compact wafer body supports both horizontal and vertical installation, with multiple end connection options to fit existing pipeline systems.
Every electric wafer type ball valve can be fully customized to your project specifications, including optional anti-static devices, custom seal materials, specialized actuator configurations, and tailored end connections, ensuring optimal performance in your specific process environment.
Our electric wafer ball valve for alcohol is compatible with a wide range of media, including water, alcohol, acid-base solutions, natural gas, oxygen, methane, and ethylene, with core applications across:
Alcohol production, brewing, and food & beverage manufacturing
Daily chemical, fine chemical, and biochemical & biotechnology industries
Pharmaceutical manufacturing and sterile process systems
Water treatment, HVAC, and refrigeration systems
Shipbuilding, papermaking, printing & dyeing, and coating production
Environmental protection and waste treatment processes
As a trusted manufacturer of industrial flow control solutions, we provide exceptional value and reliability for industrial teams worldwide:
Strict adherence to global design and testing standards, ensuring compatibility with international pipeline and automation systems
Precision in-house manufacturing and rigorous quality testing for every valve, guaranteeing consistent performance and long service life
Full customization capabilities to meet unique process requirements and project specifications
Dedicated technical support, from initial specification to after-sales service, with responsive global customer support
Transparent procurement processes, with clear lead times, pricing, and product documentation to streamline your supply chain
We offer both on-off electric actuators for simple open-close control, and intelligent modulating electric actuators for precise flow rate adjustment, allowing you to select the ideal configuration for your automation needs.
Yes. Our electric wafer type ball valve is available with corrosion-resistant body and trim materials, including 304, 316, and 316L stainless steel, along with chemically resistant seal materials, making it suitable for acid-base and corrosive process media.
The valve supports both horizontal and vertical installation in pipelines, with no restriction on mounting orientation, making it easy to integrate into existing or new pipeline layouts.
