Product Type: Signal Flanged Ball Valve
Model: XPQ41F-16P
Nominal Diameter: DN15-DN200
Operating Pressure: PN16
Body Material: WCB, CF8, CF8M, CF3M
Trim Material: 304, 316, 316L
Seat Seal Material: PTFE, PPL, RTFE, PEEK
Connecting End: Flange
Design Standard: GB/T 12237, ASME B16.34, JIS B2071, DIN 3357
Face to Face: Pioneer’s design or custom requirement
End Connection Standard: GB/T 9113, ASME B16.5, JIS B2212, DIN 2542
Inspection and Test: GB/T 26480, API 598, JIS B2003, DIN 3230
Operation Device: Handle, worm gear, pneumatic, electric actuator
Flange Hole Option: Thread drilling or through-hole
Steam Connection Option: Threaded or flange
Optional Features: Anti-static device, V-port control
Customization: Available according to customer requirements
What Are The Different Types of Butterfly Valves?Butterfly valves are essential components in fluid control systems across countless industries. Their simple design, compact size, and fast operation make them a popular choice for regulating or isolating flow in pipes. However, not all butterfly valv
When installing industrial valves, understanding flow direction is critical for proper operation, safety, and longevity. For many valve types such as globe valves and check valves, flow direction is clearly marked and must be strictly followed. But butterfly valves are different. Their unique design
In food and beverage processing, pharmaceutical manufacturing, and biotechnology production, unplanned downtime is not just costly—it can compromise product safety and trigger regulatory audits. A failing Sanitary Butterfly Valve disrupts entire production schedules, creates contamination risks, and
A butterfly valve is only as effective as the system that operates it. Even the most perfectly sealed, corrosion-resistant valve cannot perform its function if the actuation method is mismatched to the application. Understanding valve actuation options for butterfly valve systems is essential for en
The Wafer Type Ball Valve by PIONEER is a high-quality valve designed for precise flow control in various industrial applications. With its durable construction and innovative design, this valve offers efficient performance and easy installation.
Featuring bi-directional sealing, the Wafer Type Ball Valve ensures a tight seal in both flow directions, minimizing leakage. Its compact and lightweight design saves space and simplifies installation.
Suitable for a wide range of temperatures and pressures, this valve is ideal for industries such as oil and gas, chemical processing, water treatment, and power generation.
Key benefits include enhanced efficiency, reliable performance, easy installation and maintenance, versatile integration, and compliance with industry standards.
