Product Type: Signal Flanged Ball Valve
Model: XPQ41F-16P
Nominal Diameter: DN15-DN200
Operating Pressure: PN16
Body Material: WCB, CF8, CF8M, CF3M
Trim Material: 304, 316, 316L
Seat Seal Material: PTFE, PPL, RTFE, PEEK
Connecting End: Flange
Design Standard: GB/T 12237, ASME B16.34, JIS B2071, DIN 3357
Face to Face: Pioneer’s design or custom requirement
End Connection Standard: GB/T 9113, ASME B16.5, JIS B2212, DIN 2542
Inspection and Test: GB/T 26480, API 598, JIS B2003, DIN 3230
Operation Device: Handle, worm gear, pneumatic, electric actuator
Flange Hole Option: Thread drilling or through-hole
Steam Connection Option: Threaded or flange
Optional Features: Anti-static device, V-port control
Customization: Available according to customer requirements
Prevent leaks and batch contamination. Master sanitary tri clamp ball valve sizing, material selection, and flawless installation.
Avoid contamination and failed audits. Learn when to specify a sanitary tri clamp ball valve for high-viscosity fluids to maximize line uptime.
Stop sanitary ball valve leaks and costly downtime. Learn how to fix tri-clamp alignment, prevent gasket failure, and optimize CIP protocols.
Master complex fluid routing with 3-way sanitary ball valves. Compare L-port and T-port designs to reduce footprint and ensure hygienic compliance.
PIONEER presents its exceptional range of Heating Jacket Ball Valves, designed to provide efficient and reliable control in heating systems. Our cutting-edge ball valves integrate a unique heating jacket feature, ensuring optimal performance in temperature regulation applications.
Crafted with precision, our Heating Jacket Ball Valves offer enhanced heat transfer capabilities, allowing for quick and uniform heating distribution. This innovative design minimizes energy loss and promotes energy efficiency, making them an ideal choice for various industrial and commercial heating processes.
With a robust construction and high-quality materials, PIONEER's Heating Jacket Ball Valves guarantee exceptional durability and longevity, even in demanding environments. The valves are engineered to provide precise control over fluid flow, with smooth operation and minimal pressure drop.
