Product Type: Signal Flanged Ball Valve
Model: XPQ41F-16P
Nominal Diameter: DN15-DN200
Operating Pressure: PN16
Body Material: WCB, CF8, CF8M, CF3M
Trim Material: 304, 316, 316L
Seat Seal Material: PTFE, PPL, RTFE, PEEK
Connecting End: Flange
Design Standard: GB/T 12237, ASME B16.34, JIS B2071, DIN 3357
Face to Face: Pioneer’s design or custom requirement
End Connection Standard: GB/T 9113, ASME B16.5, JIS B2212, DIN 2542
Inspection and Test: GB/T 26480, API 598, JIS B2003, DIN 3230
Operation Device: Handle, worm gear, pneumatic, electric actuator
Flange Hole Option: Thread drilling or through-hole
Steam Connection Option: Threaded or flange
Optional Features: Anti-static device, V-port control
Customization: Available according to customer requirements
Learn how to select heating jacket ball valves, match heating media, and source reliable OEM partners to prevent viscous fluid solidification.
Avoid piping failures. Learn how to select the right ball valve bore geometry, mounting design, and seat materials for reliable flow control.
Avoid costly valve failures. Learn how to select the right industrial ball valve using our guide on PTM parameters, materials, and OEM sourcing.
Choose the right 3-way ball valve configuration. Compare L-Port vs T-Port flow paths, mixing vs diverting, and avoid costly industrial downtime.
The "Vacuum Angle Valve" is a high-performance sealing device specifically designed for vacuum systems. It serves as a crucial component for controlling the flow of gases or liquids and finds extensive applications in scientific research, semiconductor manufacturing, optical instruments, and other high-precision industrial fields.
Our Vacuum Angle Valve series incorporates advanced engineering design and high-quality materials to deliver exceptional performance and reliable sealing capabilities. It features a compact structure, highly precise operation, and rapid response time, enabling precise flow control and dependable sealing.
Whether operating in high-vacuum environments or under conditions of elevated temperature and pressure, our Vacuum Angle Valves offer outstanding performance and reliability. Through precision machining and advanced sealing techniques, our products ensure minimal leakage and the highest level of sealing efficiency.
