Direct Mount 3-Way Ball Valve Industrial Bypass

Direct Mount 3-Way Ball Valve is a versatile multi-port fluid control solution designed for flow diversion, mixing, and bypass applications in industrial processes. Our Direct Mounting T-Port 3-Way Ball Valve (model PQ45F-16P) features an innovative ISO5211 direct mounting platform that simplifies actuator installation and reduces maintenance costs. With robust construction and reliable performance, these valves are ideal for demanding industrial environments where precise flow control is essential.

Key Specifications

Product Overview & Working Principle

Our Industrial Bypass Ball Valve features a three-way design with two or four-sided valve seats, allowing any port to be used as an inlet without leakage. The valve is available in both L-port and T-port configurations to suit different flow requirements. L-port valves are used for diverting flow between two outlets, while T-port valves can mix flows from two inlets or distribute flow to two outlets simultaneously.

The valve ball adopts a bottom entry design that can be easily converted into a fixed ball type 3-way ball valve. The valve bonnet, bottom cover, and side cover are all assembled with bolts, enabling easy conversion to 4-way or 5-way ball valves and simplifying installation, removal, and maintenance. The ISO5211 high platform design allows actuators to be mounted directly without the need for additional mounting brackets.

Core Advantages & Design Features

Direct Mounting Platform

ISO5211 standard mounting pad for quick and easy actuator installation

Eliminates the need for costly and complex mounting brackets

Ensures precise alignment between valve and actuator for reliable operation

Modular Design

Convertible design allows easy modification to 4-way or 5-way configurations

Bolted construction simplifies disassembly for maintenance and repair

Interchangeable components reduce spare parts inventory

Enhanced Safety and Reliability

Optional anti-static device prevents electrostatic discharge

Robust body construction withstands high pressure and temperature conditions

Multiple seat seal options for compatibility with various process media

Typical Application Industries

Oil and gas processing

Chemical and petrochemical industries

Power generation

Water and wastewater treatment

Pulp and paper manufacturing

HVAC and building automation systems

Why Choose Pioneer Valve?

Pioneer Valve has been manufacturing high-performance industrial valves for professional purchasers worldwide for over two decades. Our Flanged 3-Way Ball Valves are engineered to deliver exceptional performance and reliability in the most demanding industrial applications.

We use only the highest quality materials and employ advanced manufacturing processes to ensure our valves meet the strictest quality standards. Our dedicated team of engineers and technicians works closely with our clients to develop customized solutions that address their specific flow control challenges. We also offer comprehensive technical support, fast delivery times, and competitive pricing to provide the best value for our customers.

FAQs

What is the difference between L-port and T-port 3-way ball valves?

L-port valves divert flow from one inlet to either of two outlets. T-port valves can mix flows from two inlets into one outlet or distribute flow from one inlet to two outlets simultaneously.

Can these valves be used for high-temperature applications?

Yes, with PEEK seats, our 3-way ball valves can withstand temperatures up to 260°C. PPL seats are suitable for temperatures up to 200°C.

Do you offer electric actuation options for these valves?

Yes, we offer a full range of electric and pneumatic actuators that can be directly mounted to our ISO5211 platform valves for automated operation.
