Description
The 2000PSI butt-welded ball valve is a high-performance industrial valve engineered for reliable shut-off and medium direction control in high-pressure pipeline systems. Designed to withstand rigorous operating conditions up to 2000PSI, this valve delivers exceptional sealing performance and long-term durability in critical fluid handling applications. Available in multiple configurations with threaded, welded, and tri-clamp connections, it offers versatile installation options for both horizontal and vertical pipelines, making it ideal for integration with pneumatic and electric control systems. Pioneer Valve’s 2000PSI high performance ball valve is manufactured to international standards, ensuring compatibility with global industrial infrastructure and compliance with strict safety regulations.
Product type | 2000PSI High Performance Ball Valve |
Model | PQ11F/21F/61F/6c1F/ 81F |
Nominal diameter | NPS 1/2”~NPS4”(DN15~DN100) |
Operating pressure | 2000PSI |
Body Material | WCB, CF8, CF8M, CF3Metc |
Trim material | 304,316,316L |
Seat seal material | PTFE, PPL, RTFE, PEEK etc. |
Connecting end | Threaded/ Welded/ Tri-Clamp |
Design standard | GB/T 12237, ASME B16.34, JIS B2071, DIN 3357 |
Face to face | G, NPT, BSPT, BSPP, DIN2999, ISO228 GB/T 15188/ 12224,ASME B16.25/ B16.11 |
End Connection | GB/T 9113, ASME B16.5, JIS B2212, DIN 2542 |
Inspection and test | GB/T 26480, API 598, JIS B2003, DIN 3230 |
Operation device | Handle, signal, pneumatic,electric actuator |
Design Feature | 1) ISO 5211 Direct Mounting Platform 2) Investment Casting Body 3) Blowout Proof Stem 4) Optional Anti-static Device 5) Optional V-port Adjusting 6) Optional Locking Device Handle 7) Design As Customer’s Requirement |
The butt-welded ball valve for oil and gas lines operates on a simple yet effective rotational mechanism. A hollow ball with a central bore is mounted between two seats, and rotating the ball 90 degrees using the handle or actuator fully opens or closes the fluid passage. When aligned with the pipeline, the valve allows unobstructed flow; when rotated 90 degrees, the solid side of the ball blocks the flow completely, creating a tight seal.
This design ensures minimal pressure drop across the valve, making it energy-efficient for continuous operation. The investment casting body provides uniform wall thickness and structural integrity, while the precision-machined ball and seats ensure consistent sealing even after thousands of cycles. The valve can be installed in any orientation without affecting performance, simplifying pipeline design and installation for industrial facilities.
ISO 5211 direct mounting platform enables quick and secure attachment of actuators without additional adapters
Investment casting body eliminates casting defects and ensures maximum pressure resistance
Blowout proof stem design prevents stem ejection under high pressure, enhancing operational safety
Optional anti-static device dissipates static electricity, critical for flammable media handling
Optional V-port adjusting ball provides precise flow control for proportional regulation
Optional locking device handle prevents unauthorized operation and ensures process safety
Fully customizable design to meet specific customer requirements
High-quality seat materials including PTFE, PPL, RTFE, and PEEK offer excellent chemical resistance and wear properties
Precision-machined components ensure tight tolerances and reliable operation
Easy maintenance design reduces downtime and operational costs
The 2000PSI industrial ball valve finds extensive use in industries requiring high-pressure fluid handling:
Oil and gas production and transmission
Chemical processing plants
Bio-pharmaceutical manufacturing
Shipbuilding and marine engineering
Coating and paint industries
Oils and fats processing
Brewing and beverage production
Water treatment facilities
HVAC systems
Pioneer Valve is a trusted manufacturer of high-quality industrial valves with decades of experience serving industrial buyers worldwide. Our 2000PSI butt-welded ball valves are manufactured in state-of-the-art facilities using advanced production techniques and rigorous quality control processes. We adhere to international standards including API 598, ensuring every valve meets the highest performance and safety requirements.
We offer comprehensive technical support, custom design services, and timely delivery to meet your project deadlines. Our commitment to quality and customer satisfaction has made us a preferred supplier for engineering professionals and plant operators across the globe.
The maximum operating temperature depends on the seat material. PTFE seats are suitable up to 150°C, PPL seats up to 280°C, and PEEK seats up to 300°C.
Yes, the valve is designed to handle a wide range of media including water, solvents, acids, natural gas, oxygen, and other industrial fluids.
The ISO 5211 mounting platform is compatible with standard pneumatic, electric, and signal actuators, providing flexible automation options.
