Description
As a precision-engineered flow control device, our Light Weight High Performance Butterfly Valve is purpose-built for demanding industrial applications that require weight optimization without sacrificing performance. It is the trusted choice for industrial operators, engineering contractors, system integrators and project procurement teams worldwide, with full compliance to global mainstream industrial standards.
Product type | High Performance Butterfly Valve |
|---|---|
Mode | D672F-150Lb |
Nominal diameter | NPS 2”~NPS32”(DN50~DN800) |
Operating pressure | 150Lb, PN16 |
Body Material | Cast Iron, Carbon Steel, Stainless Steel |
Trim material | 304,316,316L |
Seat seal material | RPTFE |
Connecting end | Wafer |
Design standard | GB/T 12238, API 609, JIS B2071 |
Face to face | GB/T 12221, ASME B16.10, JIS B2002 |
End Connection | GB/T 9113, ASME B16.5, JIS B2211 |
Inspection and test | GB/T 26480, API 598, JIS B2003 |
Operation device | Handle, worm gear, signal, pneumatic,electric actuator |
This high performance industrial butterfly valve features an innovative streamlined structure, delivering ultra-compact footprint, reduced weight and superior flow regulation capabilities. It is available in both soft seal and metal seal configurations to adapt to diverse fluid media and harsh operating conditions.
The valve operates via a 90-degree quarter-turn rotation of the valve stem, which drives the offset disc to open, close or throttle fluid flow. The offset design minimizes friction between the disc and seat during operation, reducing wear and extending service life, while ensuring bi-directional zero-leakage shutoff and accurate flow throttling across the full operating pressure range. It is suitable for both on-off and modulating control in complex industrial piping systems.
Compared with standard industrial valves, this lightweight high performance butterfly valve significantly reduces overall weight, simplifying handling, installation and maintenance, while lowering transportation and installation costs for large-scale projects. The compact design fits seamlessly into space-constrained piping layouts.
Equipped with a premium RPTFE seat, the valve delivers reliable zero-leakage performance even in fluctuating pressure and temperature conditions. The reinforced PTFE material offers excellent chemical resistance, wear resistance and anti-aging properties, ideal for corrosive media applications.
Manufactured in strict accordance with API 609, ASME, GB and JIS standards, every valve undergoes rigorous pressure and leakage testing before delivery, fully meeting the specification requirements of global industrial projects.
It supports a full range of actuation options, from manual handle operation to fully automated electric and pneumatic actuation, adapting to both manual and intelligent control systems.
This high performance wafer butterfly valve is widely used in critical sectors including pharmaceutical and biochemical processing, fine chemicals and paint manufacturing, oil & fat and beverage processing, industrial water treatment, environmental protection engineering, refrigeration systems, pulp and paper manufacturing, and daily chemical production.
Pioneer Valve (OULIFA) is a professional industrial valve manufacturer with decades of experience, delivering tailored flow control solutions for industrial project teams worldwide. We provide full customization based on your specific working pressure, temperature, media and connection requirements, with consistent quality, short lead times and competitive pricing. Our dedicated team offers comprehensive pre-sales technical support and after-sales service, with 24/7 assistance for product selection, installation guidance and troubleshooting.
Our light weight high performance butterfly valve is available in standard pressure ratings of Class 150Lb and PN16, covering the majority of demanding industrial piping system requirements.
Yes. With optional 304, 316, 316L stainless steel trim and RPTFE seat, it delivers excellent corrosion resistance for corrosive chemical media in fine chemical and pharmaceutical applications.
All our valves are manufactured and tested in full compliance with GB, API, ASME and JIS international standards, including API 609 design standards and API 598 inspection standards.
